Description:

Features:

• 25 Horsepower
• 992 lbs. Loader Lift Capacity At Pins
• Hydro Max Transmission
• Dual HST Pedals
• 2 Range Transmission
• Independent PTO
• Power Steering
• Selectable 4wd
• Differential lock
• 7 Year Powertrain Warranty

Specifications:

Engine

• Type: 3-cylinder, water-cooled, diesel
• Horsepower: 24.6 HP @ rated RPM
• Displacement: 77.3 in³
• Cylinders: 3
• Fuel Tank: 5.8 gal

Drivetrain

• Transmission: HST (Hydrostatic)
• Speeds: 2-range
• Clutch: None
• Brakes: Wet, multi-disc

Hydraulics

• Type: Power-assisted hydrostatic
• Hydraulic Flow: 7.0 gpm (2.8 steering + 4.2 implement)
• 3-Point Hitch: Cat 1
• Rear Remote Valve: N/A
• 3-Point Lift Capacity (24" behind): 1,101 lbs

Dimensions

• Length: 104 in
• Width: 45.8 in
• Height: 91.3 in
• Wheelbase: 57.5 in
• Ground Clearance: 9.4 in
• Weight: 1,638 lbs

PTO

• Type: Independent
• PTO Speed: 540 rpm (rear/mid)
• PTO HP: 18.8

Electrical

• Battery: 12 V, 500 CCA
• Alternator: 12 V, 40 A

Wheels & Tires (Industrial)

• Front: 23x8.50-12
• Rear: 12-16.5
